Mechanical Slurry Pump - MEC/M (NEW Series) 11000

Mechanical Slurry Pump - MEC/M (NEW Series) 11000

Store / SLURRY / BATTIONI MEC PUMPS
£1,301.03
Price incl. VAT (20%) £216.84
SIZE
In stock
Product Details
SPECIFICATIONS MEC9000M MEC11000M MEC13500M
Max flow rate 9030 lpm 11137 lpm 13845 lpm
Max rpm 600 rpm 600 rpm 600 rpm
Max absolute pressure 2.5 bar 2.5 bar 2.5 bar
Max relative pressure 1.5 bar 1.5 bar 1.5 bar
Vacuum with depression valve fitted -0.80 bar -0.80 bar -0.80 bar
Max vacuum -0.95 bar -0.95 bar -0.95 bar
Power absorption at 1.5 bar absolute, 540rpm 36 kW 21 kW 25 kW
Power absorption at 1.5 bar relative, 540rpm 17 kW 40 kW 44 kW
Power absorption at 1.5 bar absolute, 1000rpm 36 kW 21 kW 25 kW
Power absorption at 1.5 bar relative, 1000rpm 17 kW 40 kW 44 kW
Splined shaft EN ISO 500 1 3/8" 1 3/8" 1 3/8"
Valve hole BSP BSP BSP
Nett weight 145 Kg 160 Kg 178 Kg
